Connection Design & PE/SE Stamping

AI Code Compliance Check via StruxBIM™

Every connection Zenith designs is automatically verified against AISC 360-22 limit states by StruxBIM™ — with plain-English failure explanations and governing equation references. Seismic and international standards are reviewed manually by our licensed PE engineers.

Connection Design & PE/SE Stamping

Connection Engineering: StruxBIM™ Code Checks + PE/SE Stamping

Zenith provides delegated connection design for structural steel projects across the US. Calculations run through StruxBIM™, which auto-checks all AISC 360-22 limit states and flags issues before they reach drawings.

For seismic projects, our licensed PEs review AISC 341-22 system type, overstrength factors, and ductility requirements as part of the stamped calculation package. All calculations are PE-stamped and registered in the relevant US state — typically within 5–10 business days of model receipt.

Steel connection design and PE stamped calculations
Connection Types
Shear Tabs, Double Angles & End Plates
Moment: WUF-W, EF & Bolted Flange Plate
Gusset Plates: Ordinary & Seismic
Column Base Plates: Pinned & Fixed
Column & Beam Splices (Welded & Bolted)
AISC 358 Prequalified Moment Connections
StruxBIM™ Auto-Checks
AISC 360-22 §J: Weld and bolt strength, block shear, bearing
AISC 360-22 §E/F/H: Column, beam, and combined loading limits
AISC 360-22 §G: Web shear checks for coped beams
Plain-English failure explanations with governing equation reference
PE Engineer Review
AISC 341-22: Seismic systems, ductility, and overstrength — PE-reviewed
AISC 358-22: Prequalified moment connection compliance — PE-reviewed
Eurocode 3 (EN 1993-1-8) for international projects — PE-reviewed
PE-stamped calculation report, signed and sealed

PE/SE Stamping at Scale

50
US states with active PE/SE registration
AISC 360-22
Auto-checked on every connection by StruxBIM™
5–10
Business days to stamped calculation report

All Services

Get in Touch

Start Your Project

Send us your scope and one of our structural engineers will get back to you within one business day.

Contact Us
StruxBIM™AI Structural Detailing Engine
Automated Error Detection80+ detailing checks — weld callouts, cope geometry, bolt patterns — run on every drawing before delivery.
AISC 360-22 Code ComplianceEvery section auto-verified before it leaves our desk. 99.7% check accuracy.
10× Faster DeliveryAI-assisted generation cuts manual drafting time — without compromising precision.
Active — ready to process your project drawings

Get Your Connection Design Package Started

Submit your details and a Zenith structural engineer will reach out within one business day.
