Structural Steel Detailing
AI-Verified Shop Drawings, Fabrication-Ready
Zenith delivers fabrication-ready shop drawings for the full framing envelope — SMF, CBF/EBF, long-span trusses, mezzanine platforms, and pipe racks. Every project is modeled in StruxBIM™, coordinated in IFC 4.x, and issued to AISC, BS, and CISC standards in imperial and metric.
Where conventional firms rely on a single drafter's judgment, our AI layer independently validates every drawing — weld symbols, bolt grades, connection plates, and erection marks — against our live AISC 360-22 library. The result: fewer RFIs, fewer fabrication queries, schedules held.
Why StruxBIM™ Changes the Quality Game
80%
Reduction in first-review comments
10×
Faster than manual drafting workflows
99.7%
AISC 360-22 auto-check accuracy
StruxBIM™AI Structural Detailing Engine
Automated Error Detection80+ detailing checks — weld callouts, cope geometry, bolt patterns — run on every drawing before delivery.
AISC 360-22 Code ComplianceEvery section auto-verified before it leaves our desk. 99.7% check accuracy.
10× Faster DeliveryAI-assisted generation cuts manual drafting time — without compromising precision.
Active — ready to process your project drawings
